Product Description
1.The raw material will pour in A hopper, and then will enter the yellow pipe from the feed downpipe.Under the action of the wind,the raw material will enter A discharger, Combine with the action of A air lock, the wind and the raw material will be separated in the discharger. The wind will through the green pipe and then out from the cyclone.2. After enter the flour roller mill from the A air lock, the raw material will be grinded into flour and then enter the B discharger along the blue pipe, under the action of B air lock, the wind and the flour will be separated at the discharger, the clean wind will through the green pipe and then out from the cyclone.The flour will along the red arrow through the B air lock and then enter the round screen. The qualified flour will out from the middle hopper of round screen and then packed.Unqualified flour will out from the top of round screen,through the guide plate (Cyan) enter the B hopper. 3.When the raw materil in A hopper finished, the guide plate under the hopper will change from A to B for feeding,the guide plate on top of hopper will guide the unqualified flour into the A hopper.Operate like this (From A to B hopper,and then from B to A hopper) for sometimes,until the unqualified products doesn’t incude flour.4.Finally, the rest material will be let out from the outlet of the machine.Finished product
Details Images
Packing & Delivery
Our Company
Why Choose UsCompared with others, we are the manufacturer, so we can make delivery in time and supply products with high quality and reasonable price,which are our outstanding advantagesOur ServiceAcceptance standard
Unless stipulated in the technical documents accordingly, technology acceptance standards of designed main parts are in accordance with relevant state departments issued current relevant standards. providing main parts technology acceptance standard of technical design. Technical service
During flour mill machinery installation, We cooperate with buyer for technological improvement to reach desired results. We explains flour mill machinery performance, structure and operation to buyer related people for free.
Quality guaranteed
We will make sure our flour mill machinery achieve promised performance with correct installation, commissioning, normal operation and maintenance. In warranty period, for quality problem, we repair and replace defective parts for free(except quick-wear part).Contact Us
Automatic Small type 200kg/h Rice flour milling machine
Features:
1.Automatic feeding in the easiest way, continuous milling can reduce the labor intensity largely.
2.Pneumatic conveying minimize dust and improve the working environment of workers, reducing the temperature of the article.
3.Easy operation and maintenance, small investments and yield quick returns.
![](/uploads/allimg/200519/waldth0uucj23936.jpg)
![](/uploads/allimg/200519/uhnpubnbv0123937.jpg)
![](/uploads/allimg/200519/1kqjyitdejp23938.jpg)
![](/uploads/allimg/200519/00h5ldletex23939.png)
![](/uploads/allimg/200519/xlxkcedt24d23940.jpg)
Unless stipulated in the technical documents accordingly, technology acceptance standards of designed main parts are in accordance with relevant state departments issued current relevant standards. providing main parts technology acceptance standard of technical design. Technical service
During flour mill machinery installation, We cooperate with buyer for technological improvement to reach desired results. We explains flour mill machinery performance, structure and operation to buyer related people for free.
Quality guaranteed
We will make sure our flour mill machinery achieve promised performance with correct installation, commissioning, normal operation and maintenance. In warranty period, for quality problem, we repair and replace defective parts for free(except quick-wear part).Contact Us
![](/uploads/allimg/200519/jcpuco22zvb23941.jpg)
Applicable Industries:Food & Beverage Factory, Home Use
Condition:New
Place of Origin:Henan, China
Brand Name:Yubei
Production Capacity:100-200kg/h
Voltage:380V/50Hz/3Phase
Power(W):13.2kw
Weight:750kg
Dimension(L*W*H):2.5m*2m*3.2m
Certification:ISO9001:2008
Warranty:1 YEAR
After-sales Service Provided:Field installation, commissioning and training
Name:Automatic Small type 200kg/h Rice flour milling machine
Material:carbon steel
Color:White
Raw material:white rice,broken rice
Final products:rice flour
Feature:automatice feeder
Processing type:Grain Milling Line
Advantage:Fine Powder Making Machine
Used for:Flour Milling Process
Capacity:100-200kg/h
Condition:New
Place of Origin:Henan, China
Brand Name:Yubei
Production Capacity:100-200kg/h
Voltage:380V/50Hz/3Phase
Power(W):13.2kw
Weight:750kg
Dimension(L*W*H):2.5m*2m*3.2m
Certification:ISO9001:2008
Warranty:1 YEAR
After-sales Service Provided:Field installation, commissioning and training
Name:Automatic Small type 200kg/h Rice flour milling machine
Material:carbon steel
Color:White
Raw material:white rice,broken rice
Final products:rice flour
Feature:automatice feeder
Processing type:Grain Milling Line
Advantage:Fine Powder Making Machine
Used for:Flour Milling Process
Capacity:100-200kg/h
- Packaging Details
- Plywood case
- Port
- Shanghai,Qingdao,Tianjin
- Picture Example:
-
- Lead Time :
-
Quantity(Sets) 1 - 1 >1 Est. Time(days) 7 To be negotiated
